Technical parameter：
• Designing temperatures: 160°C
• Maximum working temperature: 140°C
• Maximum working pressure: 0.55MPA。
• Heating rate: average 3.5°C/min, (calculated based on 0.7MPA dry saturated steam)
• Cooling rate: average 2.5/min (calculated with 0.3MPA, 25°C cooling water)

SPECIFICATIONS：

Model	Work capacity	Power	Height
GXY ( HB ) AW-200	1000-1300KG	37-45KW	7800
GXY ( HB ) AW-200	1500-1800KG	45-55KW	8800

Features :
• Mainly for deseeding and bleaching of cotton;
• Adopt single-piece unidirectional pipeline pump design;
• Disc-type heat exchanger with strong stream and effective heating;
• Automatically controlled technology of dehydrating and bleaching;
• The water permeability of the outer tube and inner tube of the sarong is increased by 15%, achieving a strong seed removal effect;
• Feasible bath ratio: 1:4~5
